Geekcreit® DC 12V 4CH Channel Wireless Remote Control Switch Learning Type Relay Control Module With Case

Main Technical Indicators 1 Working Voltage DC12V2 Static Working Current 6mA3 Working Temperature 40C 80C4 Receive Sensitivity 105dBm5 Working Frequency 433MHz6 Output voltage AC DC optional7 Output current 3A Receive Terminal Description V power positive inputGNDpower supply negative input1 KC1 relay normally closed end2KC1 relay public end3 KC1 relay Normally open end4 KC3 relay normally closed end5 KC3 relay public end6 KC3 relay Normally open end7 KC2 relay normally closed end8 KC2 relay public end9 KC2 relay Normally open end10 KC4 relay normally closed end11 KC4 relay public end12 KC4 relay Normally open end Instructions 1 Jog function Press the control board code button once the LED indicator flashes once wait for the LED indicator to light up press the remote control button that needs to be coded and the control panel LED indicator flashes 3 times continuously The code is successful 2 Self locking function press the control board code button twice in succession the LED indicator flashes 2 times and when the LED indicator lights up press the remote control button that needs to be coded and the control panel LED indicator flashes 3 times continuously The code is successful 3 Interlock function press the control board code button 3 times in succession the LED indicator flashes 3 times wait for the remote control button of the code to be pressed after the LED indicator lights up the control panel LED indicator flashes 3 times
