GeekTeches® 3.2 Inch TFT LCD Display + TFT LCD Shield For Arduino Mega2560 R3

Overview: 3.2" TFT LCD Display is a LCD touch screen module. It has 40pins interface and SD card and Flash reader design. It is a powerful and multifunctional module for your project. The Screen include a controller SSD1289, it's a support 8/16bit data interface easy to drive by many MCU like STM32 ,AVR and 8051. It is designed with a touch controller in it . The touch IC is ADS7843 and touch interface is included in the 40 pins breakout. It is the version of product only with touch screen and touch controller. Specification: 240374PQ 65K color 320*240 3.2 inch Wide viewing angle SSD1289:240 RGB x 320 TFT Driver Integrated Power, Gate and Source Driver With RAM ADS7843:4-WIRE TOUCH, UP TO 125kHz CONVERSION RATE, SERIAL INTERFACE Feature: 3.2 TFT LCD shield works in 3.3V voltage level and you need to use cables to connect with Arduino Mega. And this shield can help you out of the bothers to use other cables. You just need to plug the module to Mega through this shield. This shield supports both 16 bit mode. And Mega board has enough pins for using SD card and touch function at the same time. It also has an adjustable button for contrast of the LCD display. Package includes: 1 x 3.2 inch TFT LCD 1 x Mega Shield Board
