Geeetech® TL-touch Auto Bed Leveling Sensor With High Compatibility For 3D Printer

Features: -This is an auto leveling sensor for 3D Printers based on open-source. -Simple, Smart, High-precision, It could work with any kinds of bed materials, such as glasses, woods, metals, and so on. -It can be operated in the following conditions: -One I/O for control (PWM or Software PWM) -One I/O for Zmin(Z Probe) -GND and +5V power Notes: -Additional power supply can be needed in case which your board does not supply enough amperage. -Electronic devices can be damaged or even destroyed if connected to the wrong side polarity. [wrong terminal connect to 5V(+) and GND(-)] -Install BLTouch as far as it possible from magnetic, motor, fan etc. -The action as pulling/pushing hard the push-pin can make the BLTouch damaged and less accurate. -Fix push-pin with locking paint after reassembling or adjusting core. -Please do not change the position of the hex screw(core). -Do not separate or deform elastic material attached on the push-pin. -The action(Pull or push push-pin hard) makes damage and lowers the accuracy of sensor Package Included: 1 X Sensor 1 X 3Pin Straight Pin 1 X 2Pin Straight Pin 2 X Screw & Nut & Washer 2 X Dupont Housing Shell 3Pin 2 X Dupont Housing Shell 2Pin 10X Dupont Terminal 1 X 10K 1/8W Resistor for Smoothieboard Here are more info. for your reference: 1. More product info. 2. Common probe adaptation model 3D STL 3. Video info. 4. User maunal
