Gauss Tesla Tester GS100D Magnet Meter Landtek GS-100D Magnetic Field

Alat ukur medan magnet kelas industri dari Landtek
Dengan satuan Tesla atau Gauss
Mengukur sampai 2000 Mili Tesla (2 Tesla)
Ideal untuk pengukuran industri, safety, lab, riset, dll
- Original Landtek
- Dikirim dari Jakarta dengan kardus double utk keamanan produk
- Semua produk kami bergaransi distributor Jakarta
===
Used for measuring the magnetic induction intensity of DC magnetic field, AC magnetic field, radiation magnetic field, remanence magnetic field, earth magnetic field, and other magnetic fields.
Features
* Portable, wide range.
* Easy to operate, clear LIQUID crystal display.
* There are measurement/peak retention, mT/Gs unit conversion.
* 200mT/2000mT range conversion, etc.
Principle
The tension sensor is based on Hall's principle.The circuit uses a low drift amplifier and a high stable power supply, controlled by a single chip microcomputer, and displays the measured values on a 41/2LCD.
Specifications
Measuring range 0~200mT~2000mT
Frequency range 10Hz~200Hz
The accuracy of: 0~100mT 2%, above 100mT 5% (measured in a uniform magnetic field)
Magnetic field under test: Dc magnetic field (static magnetic field)
Functional specifications: Peak retention Gs(Gauss) /mT (Millitesla) can be switched freely
Dc polarity of measurement: N for positive, S for negative
Operating Conditions: 5℃~40℃
Relative humidity: 20%~80%（There is no dew）
Power supply: Four no. 5 batteries can be externally connected to a 5V stabilized voltage supply
Overall dimensions: 140mm (L) X73mm (W) X 30mm (H)
Instrument weight: 180g
Display mode 4 1/2LCD
According to the unit mT/Gs
Standard Accessories
Main unit
Hall sensor
Operating Instruction
