GY-LSM9DS 9 Axis Sensor Module Acceleration Gyro Magnetometer Inertial Measurement Accelerometer Unit IMU Geekcreit for

More details click to download LSM9DS1Description The LSM9DS1 is a system in package featuring a 3D digital linear acceleration sensor a 3D digital angular rate sensor and a 3D digital magnetic sensor The LSM9DS1 has a linear acceleration full scale of 2g 4g 8 16 g a magnetic field full scale of 4 8 12 16 gauss and an angular rate of 245 500 2000 dps The LSM9DS1 includes an I 2 C serial bus interface supporting standard and fast mode 100 kHz and 400 kHz and an SPI serialstandard interface Magnetic accelerometer and gyroscope sensingcan be enabled or set in power down mode separately for smart power management The LSM9DS1 is available in a plastic land grid array package LGA and it is guaranteed to operate over an extended temperature rangefrom 40 C to 85 C Features 3 acceleration channels 3 angular ratechannels 3 magnetic field channels 2 4 8 16 g linear acceleration full scale 4 8 12 16 gauss magnetic full scale 245 500 2000 dps angular rate full scale 16 bit data output SPI I 2 C serial interfaces Analog supply voltage 1 9 V to 3 6 V Always on eco power mode down to 1 9 mA Programmable interrupt generators Embedded temperature sensor Embedded FIFO Position and detection functions Click double click recognition Intelligent power saving for handheld devices ECOPACK RoHS and Green compliantApplications Indoor navigation Smart user interfaces Advanced gesture recognition Gaming and virtual reality input devices Display map orientation and browsingPackage In
