GY-BNO055 9DOF 9-axis BNO055 Attitude Sensor Angle Gyroscope Module

Features Module Model GY BNO055Use the chip BNO 055Power supply 3 5v internal low voltage regulator Communication method standard IIC serial communication protocolCommunication Module size 12mm 20mm Applications Bosch Sensortec BNO055 Intelligent 9 Axis Absolute Orientation Sensor is a System in Package SiP integrating a triaxial 14 bit accelerometer a triaxial 16 bit gyroscope with a range of 2000 degrees per second a triaxial geomagnetic sensor and a 32 bit ARM Cortex M0 microcontroller running Bosch Sensortec sensor fusion software in a single package The corresponding chip sets are integrated into one single 28 pin LGA 3 8mm x 5 2mm x 1 1mm housing For optimum system integration the BNO055 is equipped with digital bidirectional I2C and UART interfaces The I2C interface can be programmed to run with the HID I2C protocol turning the BNO055 into a plug and play sensor hub solution for devices running the Windows 8 0 or 8 1 operating system Package Included 1 x BNO055 Attitude Sensor Angle Gyroscope Module
