GY-955 GY-BNO055 9DOF Sensor Angle Gyro Module 9 Axis Navigation Module Acceleration Gyroscope Magnetometer

More ducument click to download: GY-BNO055 Overview: GY955 is a low cost AHRS module. Working voltage 3-5v power consumption is small, small size. Its working principle is through the gyroscope with Acceleration pass, magnetic field sensor through data fusion The algorithm finally gets direct angle data. This module uses the serial (TTL level) way of communication. The product has high precision and high stability. Able to get an accurate angle in any position, Serial baud rate of 9600bps and 115200bps There are two ways of continuous output and inquiry output, Can adapt to different working conditions. With all the microcontroller and computer connection. Specifications: Measuring range: -180 ~ 180 Resolution: 0.01 Measurement accuracy: 2 Repeatability: 2 Response frequency: 100 HZ (115200 bps) Working voltage: 3 ~ 5 V Working current: 15mA Operating temperature: -20 ~ 85 Storage temperature: -40 ~ 125 Size: 14.6mm 17.8mm Features: Built-in MCU calculation angle small volume Serial communication format With the corresponding host computer software Applications: Handheld instrumentation Robot navigation, positioning Voyage model system Balance car Antenna pitch positioning Pin Description: VCC: Power supply + (3v-5v) TX: Serial UART_TX (TTL level) RX: Serial UART_RX (TTL level) GND: Power ground SI: Reserved, do not connect SR: Reserved, do not connect REST: BNO055 REST pin ADD: BNO055 I2C address pin SDA: BNO055 I2C data pin SCL: BNO055 I2C clock pin Package Included: 1 x GY-955 GY-BNO055 9DOF Sensor Angle Gyro Module
