GLFILL 5V-24V 3A Led Capacitive Module Touch Switch Dimming Control Lamp Sensor

Features: - brand new and high quality - Made of high quality materials durable and practical - Function Mode Selection: Default is Mode 1: - That is the pads 123 are not soldered OPT1 OPT2O PT3 is: 111 - do not solder - 1 for soldering to 0 - Mode OPT1 0PT2 OPT3 Dimming method - The default is high level 1 when the pad is floating and low level 0 when the pad is shorted; - Brightness memory does not refer to power-off memory it means that after the module is powered on the touch switch process has brightness memory; when the module is powered off the brightness will return to the default state: - Application scenarios: wardrobe cabinet lights display cabinet lights LED hard light strips light strips aluminum trough lights touch eye protection table lamps etc. (Material for panels: insulating materials ordinary glass tempered glass plastic wood paper stone etc.) Product parameters: - Input voltage DC5V-24V (recommended 12V) output voltage equal to input voltage - Load power 72W(MAX) - Load current resistive 3A(MAX) - Standby current 10-15mA - Standby power consumption ~0.01W - Working temperature -25°C-85°C - Output frequency 32KHZ - Product weight ≈15g - Product size: length 42 width 12 height 14 (MM) Kind tips: - The input voltage cannot be lower than 5V or higher than 24V 12V is the best. - The load power cannot be higher than 72W otherwise there will be induction and the load will not act. - Do not reverse the input and output IN is input OUT is output otherwise it will burn out the circuit. Package Included: 1* LED Capacitor Module Touch Switch Notes: 1. Due to various factors such as display brightness and light brightness the actual color of the product may be slightly different from the website picture. 2. Please allow a slight deviation between the data and the manual measurement.
