Fast Shipping ETCR068B Clamp leakage current sensor test leakage current, high order harmonic current,phase test Range 0~1000A
Technical Details
| Accuracy Class: | +/-2.0%FS(50Hz/60Hz;23C+/-2C, below 70%RH, keep the wire |
| Brand Name: | YINCALI |
| Coil turns: | Standard 1000:1(customize is allowed) |
| CT size: | 68mm |
| Current frequency: | 45Hz~60Hz(Current to be measured) |
| Dimensions: | 185mm*115mm*43mm |
| Display Type: | Digital Only |
| DIY Supplies: | Electrical |
| Frequency: | 10Hz~100kHz |
| Lead Length: | 2m |
| Model Number: | ETCR068B |
| Operating Temperature: | -20C-50C below 80%RH |
| Phase Error: | less than or equal to 3 degree(AC50Hz/60Hz; 23C+/-2C) |
| Range: | 0.00mA~1000A |
| Resolution: | 1mA |
| shield: | Clamp without shield layer |
| Supply Voltage: | Circuit with the voltage below AC 600V |
| Test mode: | Clamp CT |
| Warranty: | One year |
