FUKUDA EK-453DP 5 Lines 3 Points 4V1H Cross Line Laser Rotary Laser Level

Description: FUKUDA EK-453DP 5 Lines 3 Points 4V1H Cross Line Laser Rotary Laser Level Automatic Anping (gravity pendulum - magnetic damping) mode, easy to use and reliable. Laser with a wavelength of 635nm makes laser lines clear and bright. Create a vertical line and a horizontal line orthogonal to each other, vaginal discharge point (red). Can be used indoors and outdoors. Easy-wide fine-tuning mechanism, 360rotating, stable and flexible, can be precisely identify the target. Specification: Horizontal accuracy 1mm / 5m Vertical accuracy 1mm / 5m Under point accuracy 1mm / 1.4m Orthogonal accuracy 90 60 " Zenith precision 2mm / 3m Automatic Anping range approximately 2.5 Launch angle vertical lines 110 horizontal 130 Laser wavelength vertical and horizontal 7x635nm; next point 1x650nm Working distance indoor working radius of about 10m; using detectors, working radius 50m Laser emitted power 1mw less (safety standard 2) Power 4.5V (3xAA battery) not included Operating temperature 5 C - + 40 C Size 90 () X195 (H) mm Weight 1.6kg Continuous working time about 6 hours (full brightness laser tube) How to use: Set the instrument on the tripod or a stable surface, adjust the instrument. If the instrument is too tilted, out of range, the laser tube will automatically turn off (or if audible alarm) Switch knob clockwise to open the instrument, the instrument top green indicator light, while emitting a laser beam Turn the instrument, the laser beam toward goals Gently adjust knob, find work orientation When work is over, turn the switch knob counterclockwise, turn off the instrument . With light point designed outdoor environments, provide convenience for the construction. Package includes: 1 x Plastic protective case 1 x 5 Lines Laser Level ( Two colors for opition~) 1 x AC110-240V Power supply 1 x protective glasses 1 x reference plate 1 x Belt Details pictures:
