FPV Multi-camera Mini Two-way Electronic Switch Video Switcher Module for RC Drone FPV Racing

FPV Multi-camera Mini Two-way Electronic Switch Video Switcher Module for RC Drone FPV Racing
Eachine1
sku: 973356
ACCORDING TO OUR RECORDS THIS PRODUCT IS NOT AVAILABLE NOW
$4.92
Shipping from: China
   Description
FPV Multi-camera Mini Two-way Electronic Switch Video Switcher Module No OSD Wiring Method 1: No OSD Wiring Method 2: With OSD wiring method 1: With OSD wiring method 2: Description: Item Name:AV Video Switcher Video Switcher Board Size (Not Included Pins):16 x16mm Weight:1g Features: Enjoy the perspective of different directions You can switch the two cameras or AV signals of DV by controlled transmitter,were respectively switched to the OSD or video transmitter. Dedicated video switching IC, no loss of quality, no switching life, ultra-small resistance It can work with 3.3-12V camera . Notice: Video switcher can access any channel receiver to use, practical advice to use two-way switch or knob channel to use. AV_IN1 and AV_IN2 for two-way video input AV_OUT for video outputs PWM Connect the receiver to any channel 5V connected receiver 5V GND connected ground line of receiver Please be careful that the wiring sequence when use it, video switching module itself is power supply by the receiver 5V, 12V not access the video wire. Indicator Explanation: Long bright--Module's PWM signal input is abnormal--AV_IN1 communicate with AV_OUT Quick flash--Module's PWM signal input is normal--AV_IN1 communicate with AV_OUT Slow flash--Module's PWM signal input is norma--AV_IN2 communicate with AV_OUT Package Included: 1x AV Video Switcher (Not Included Receiver)
