Eachine 32bits F3 Brushed Flight Control Board Based On SP RACING F3 EVO For Micro FPV Frame

Eachine 32bits F3 Brushed Flight Control Board Based On SP RACING F3 EVO For Micro FPV Frame Description: Brand Name: Eachine Item Name: F3_EVO_Brush Flight Control Dimension: 22mm*32.5mm Thickness: 1.2mm Weight: 3g Features: 1. F3_EVO_Brush is in the revision on the basis of the F3 EVO SP RACING,it is a 32bits brush flight controller based on SP RACING F3 EVO firmware. 2. The flight control support 1S (4.2V) and 2S (8.4V) power supply, 2S power can bring flying experience more violence. 3. Independent design of the circuit structure, comes with the pressure reduction technology, whether it is 1S or 2S power input, UART1/2 output 5V, UART3 output 3.3V 4. Using STM32F303CCT6 + MPU6500, advanced hardware platform F3 guarantee more stable flight. 5. With a 6-ways large current NMOS transistors, operating current of up to 10A or more. Each machine is equipped with freewheeling diodes. 6. Support for PPM, SBUS, DSM receiver input signal. 7. With battery voltage detection and buzzer interface. 8.In support of the world almost all hollow cup motor, including 1020 coreless motor.Support 6 motor. Notice: Before applying power, pay attention to the battery voltage selection. The default shipping is 1S (4.2V); When using 2S, first need to disconnect the short contacts 1S, and then put the two pads on the 2S. Prohibit shorted together the three pads at the same time. Receiver configuration: 1. DSM receiver soldered directly to the DSM interface 3.3V, GND, RX3, in CF software configuration UART3 for Serial RX, and change the Receiver mode to RX_SERIAL,and then set up the receiver brand with Spektrum1024 or 2048. 2. SBUS receiver soldered on GND,+5V,RX2 Pin of UART2.SBUS signal in CF software configuration UART2 for Serial RX,and change the Receiver mode to RX_SERIAL,and then set up the receiver brand with SBUS. 2. PPM receiver soldered on GND,+5V,RX2 Pin of UART2.No need to open RX Serial, just in the CF software to change the Receiver mode for RX_PPM. Package included: 1 x Eachine F3_EVO_Brush Flight Control Board
