ET430 Handheld LCR Meter 100KHz LCR Digital Bridge Meter Capacitance Inductance Resistance Meter High Precision LCR Bridge Meter

ET43 series handheld bridge features 2.8" TFT display screen, easy key operation and USB communication. Its high capacity lithium battery ensures long run. It can measure comprehensive parameters, and supports for screening and deviation measurement, with continuously adjustable output frequency. The basic precision reaches 0.2%. Features: The measurement frequency reach to 100kHz, the 1Hz stepping can be adjusted continuously. DC resistance, electrolytic capacitance measurement Internal bias voltage output (10mV-500mV) Automatic identification of component measurement Support for screening and deviation measurement 2.8 inch TFT display, 4 half display USB communication interface Large capacity lithium battery power supply Support SCPI protocol Provide system settings, according to their own requirements configuration language, buzzer, screen brightness, etc. Basic measurement accuracy 0.2% measurement speed can be adjusted Manual and automatic range Open circuit fault Specification: Model ET430B ET430 ET431 ET432 ET433 Measurement parameters Main parameter:L/C/R/Z Secondary parameter:X/D/Q//ESR Equivalent mode Series, parallel Mode of range Manual, automatic Measurement speed Fast(4 times/s) medium(2 times /s) slow(1 times /s) Configuration of the test terminal 3-terminal, 5-terminal Correctionfunction Short circuit, open circuit Communication interface Mini-USB(virtual serial port) Frequency of test signal 100Hz, 120Hz, 1kHz, 10kH 100Hz, 120Hz, 1kHz, 10kHz, 40kHz, 100kHz 100Hz, 120Hz, 1kHz, 10kHz 100Hz, 120Hz, 1kHz, 10kHz, 40kHz, 100kHz 10Hz-100KHz adjustable, 1Hz stepping Level of test signal 0.6Vrms 0.6Vrms,0.3Vrms, 0.1Vrms 0.1Vrms-0.7Vrms adjustable, 1mVrms stepping Output impedance 100 Highest accuracy (see accuracy indicators for details) 0.3% 0.2% Electrolysis and capacitance mode No Yes DCR mode No Yes Internal bias No 0-500mV adjustable, 1mV stepping Scope of measurement L:0-2000H C:0-20mF R:0-20M Package includes: 1 X ET430 LCR Meter 1 X USB Line 1 X US Plug (We will send you a plug adapter according to your country.) 1 X Test Cable 1 X English User Manual Details pictures:
