ESCAM WNK403 4CH WiFi NVR Kit P2P 720P Access Point Outdoor IR Night Vision IP Camera System (Adaptor: EU Plug)

Specification : Wireless NVR Specification ESCAM WNK403 video input Network Video 4CH Network video input broadbank 20Mbps video output HDMI input 1ch, resolution: 1024x768, 1366x768, 1440x900, 1920x1080p VGA output 1ch, resolution: 1024x768, 1366x768, 1440x900, 1920x1080p AV CODEC Specification Video Resolution 720P synch-playback 4CH Video Control Video/Capture mode Maual/Time/Motion/Alarm Playback mode Real time/Routine/Event Backup USB backup Hard Disk Type 1*SATA interface Max Capacity 4 TB at most for each External Interface Network Interface one adaptable RJ45 10M/100M, one 2.4Ghz WIFI interface USB Interface USB 2.0 Network Control Protocol UPnP (play&plug)/SMTP (email survice)/PPPoE (dial-up) DHCP (Automatically obtain an IP address) Others Power Supply DC12V2A Power Consumption (W) ≤5W(Without HDD) Operate Temperature (°C) -10? to +55? Working Humidity (%) RH 10%~90% Weight(excluding HDD) 0.73Kg Dimensions 257x210x42mm IPC Specification Sensor 1/4” Progressive CMSO Sensor Signal System PAL/NTSC Resolution 1280 x 720 Minimum illumination Color: 0.1 Lux; B/W: 0.01 Lux Shutter 1/25s to 1/25,000s Lens 3.6mm OSD Date Time & Title White Balance Auto Day&Night Auto / Color / BW 3D-DNR Auto Mirror/Flip On / Off Frame Specification Three Streaming at the Same Time: H.264 1280x720@15fps or below H.264 640x480@30fps or below S/N > 39.1 Db Interface RJ45 / WIFI 802.11b/g/n General Specification Anti-thunder Level Standard IEC61000-4-5 Working Temperature/Humidity -10? to +50? / 30% to 80% RH Working Temperature/Humidity -20? to +60? / 20% to 90% RH Power Input DC12V1A Power consumption ≤6W Level of Protection IP66 Weight 0.25kg Dimensions 107x68x60mm Package Package Dimension 340x185x270mm Package Weight 2.8kg Please note that IP camera inside WiFI NVR KIT WNK403 is different from QD300WiFi and QD900WiFi. Package includeds : 1 x WiFi NVR 4 x WiFi Camera 5 x Screw Bag 1 x Mouse 5 x Power Adapter (EU / US / UK / AU Plug for Optional~) 1 x User Manual 4 x Waterproof Hat 1 x Network Cable Details pictures :
