EDUP EP-AB007 2.4GHz 4W Wireless Repeater WiFi Range Extender WiFi Signal Booster

This Wireless WiFi Repeater designed to enhance radio signals to increase the effective range and coverage for Wi-Fi communication. 20 times the power, improving the link quality and coverage of certified WLAN devices. It will help easily construct a wireless infrastructure for homes or businesses environments while saving you a lot of wiring costs.
Features
20 times the power, improving the link quality and coverage of certified WLAN devices.
2.5dB ultra-low noise.
Wide 6V to 18V operating input range.
Working with certified IEEE802.11 b/g/n wireless LAN devices.
Simply plug and play, no software needed.
Compact design.
How to Connect
Step 1: Remove the antenna from the wireless router (access point).
Step 2: Use RG316 cable to connect the booster and AP.
Step 3: Connect the antenna to the other end of booster.
Step 4: Plug in the power adapter.
Specifications
Standard IEEE 802.11b/g/n
Frequency Range 2.4-2.5GHz
Working Pattern TDD
RF Output Power 36dBm (4W)
Input Trigger Power Min 3dBm; Max 20dBm
Transmission Gain 13dB + 1
Receiving Gain 10dB + 1
TX/RX Switch Time Delay
