EDUP EP-9635 PCI-E Gigabit Network Card 10/100/1000Mbps/2.5G RTL8125 Chip RJ45 Ethernet LAN Adapter PCI Express Network

Features ● Integrated 10 100 1000M 2 5G transceiver ● Supports 2 5G and 1G Lite mode ● Auto Negotiation with Extended Next Page capability XNP ● Supports PCI Express 2 1 ● Supports pair swap polarity skew correction● Configurable MDI port ordering MDI swap for easy PCB layout ● Crossover DetectionAuto Correction ● Supports 1 Lane 2 5 5Gbps PCI Express Bus ● Embedded OTP memory can replace external EEPROM● LAN disable with GPIO pin ● Customized LEDs ● Controllable LED Blinking Frequency and Duty Cycle ● Self Loopback diagnostic capability ● Thermal management ● 88 pin QFN Green package ● Serial EEPROM ● Supports 32Mbytes External Serial Peripheral Interface SPI Flash ● Supports ECMA 393 ProxZzzy Standard for sleeping hosts ● Supports LTR Latency Tolerance Reporting ● Wake On LAN and RealWoW Technology remote wake up support Specifications Brand EDUP Model EP 9635 Chipset RTL8125 Port number 1 RJ45 Standard IEEE 802 3 IEEE 802 3u IEEE 802 3ab IEEE 802 3az IEEE 802 3bz Network media 10Base T cat3 or above UTP 1000Base Tx cat5 or above UTP Data rate 10 100 1G 2 5Gbps Interface PCI Express 1x slot Auto MDIX YES Full Duplex Support YES MTBF 376 212 Hours LED Indicator Link Act Speed Dimension 71 5 50 1 6mm Supported Operating System Windows®10 32 64 Win7 32 64 Win8 8 1 32 64 Windows Server® 2012 2008 LINUX up to 4 15 Environment Operating Temperature 0 ℃ 60 ℃ Relative Humidity 10 90 non condensing Storage Temperature 10℃ 70℃ Relative Humidity 5 90 non con
