Docooler 2.4Inch TFT LCD Display Dual Channel Function Arbitrary Waveform Generator 200MSaS Sampling Rate 13 Bit Vertical Resolution 8k Storage Depth Signal Source Frequency Meter

Docooler
sku: 1606385310
ACCORDING TO OUR RECORDS THIS PRODUCT IS NOT AVAILABLE NOW
$125.89
Shipping from: United States
Description
Please note this item ships from an international seller. Expected delivery is 10-15 days. This two-channel arbitrary waves generator adopts direct digital frequency synthesis technology which can output signals with high accuracy stability and low distortion. 2.4-inch TFT LCD display 320*240 resolution with clear graphic interface. 200MSaS sampling rate 13bit vertical resolution and 8k storage depth. The measurement mode has 2 functions one is a frequency meter (frequency measurement) the other is a counter (count the number of pulses). With four modulation modes of pulse//burstmodulated output. 5 basic waveforms and 32 arbitrary waveforms in-built. Support internal storage of 50 groups of user-defined edited waveforms. Features: Independent Channel: Both channels are independent of each other and have phase synchronization function. Basic Parameters: Sampling rate: 200MSa/S vertical resolution: 13bit and storage depth: 8k. Digital Display: 2.4-inch TFT LCD display 320*240 resolution with clear graphic interface. Measurement Mode: The measurement mode has 2 functions one is a frequency meter the other is a counter. They measure digital signals from the external input port. Frequency Meter: The frequency meter is used to measure the frequency. The frequency is measured by equal precise measurement. The coupling and gate time can be set. Pulse Counter: With 100MHz high precise frequency meter and 32 bit counter. The counter is used to count the number of pulses and can be set to turn on the coupling and function as well as the number of zeroes. Four Modulation Modes Design: Support for pulse/sweep/burst/modulated output. System Settings: The system Settings page displays the current software version.It can load and save the system parameters set the buzzer to open and close the brightness of the screen the English and Chinese language switching and edit save and load any wave calibrate and restore factory Settings. Waveform Types: 5 basic waveforms(sinewave squarewave rampwave pulsewave noisewave) and 32 arbitrary waveforms in-built. Waveform Storage: Support internal storage of 50 groups of user-defined edited waveforms. Settable Time Edges: Pulsewave output set in edgestime. AM/FM/PM Modulation Function: Internal AM frequency modulation PM modulation function (External AM frequency modulation PM modulation is optional). ASK/FSK/PSK Modulation Function: Internal/external ASK FSK PSK modulation function. 60M Channel Output Frequency: Dual channel output maximum output frequency 60M. Waveform Output: Output of linear/logarithmic sweep and burst (pulse train) waveforms. Standard USB Device Interface: Optional external analogue modulation interface. Communication Extension Interface: The 10P communication extension interface of ET33C extends TTL digital signal and serial signal. Software Support: Equipped with multifunctional arbitrary waveform editing software. Three Models Available: ET3320C ET3340C ET3360C the highest output frequency is 20MHz 40MHz and 60MHz respectively. Specifications: Name: Waveform Generator Material: plastics Type: ET3320C 20MHz -Plug ET3340C 40MHz -Plug ET3360C 60MHz -Plug ET3320C 20MHz USA-Plug ET3340C 40MHz USA-Plug ET3360C 60MHz USA-Plug (optional) Packing List: 1 * Waveform Generator 1 * Three-core Power Cable 2 * BNC Coaxial Cables 1 * USB Data Cable 1 * Straight Signal Cable
