Decimator DMON-QUAD 4-Ch 3G/HD/SD-SDI Quad Split Multi-Viewer with HDMI Outputs

• Supports 3G level A and B on inputs and output, allowing conversion between 3G level A and B• Low cost (3G/HD/SD)-SDI 1 to 4 Multi-Viewer or 4 to 1 input multiplexer• Custom Layouts with various standard layouts• 16 Character UMD overlay per window with individual enables, custom positioning and size• 8 Channel Audio Metering overlay per window with individual enables, custom positioning and size• Horizontal and/or Vertical image flipping per window• Audio ID overlay• Tallies can be applied to either Tally Boxes (Default) or Border• Tally boxes allows for up to 4 Tallies per window• Fast switching between inputs using Full-Screen scaling• Selectable output format in both Full-Screen Multi-Viewer mode• Low latency buffering for each input allowing non-synchronous inputs• Linked (3G/HD/SD)-SDI and HDMI outputs• 4x (3G/HD/SD)-SDI inputs with auto detection (26 Formats supported in total)• Each window is independent of the others, allowing any 3G/HD/SD format of any frame rate to be displayed simultaneously• Variable aspect ratios per window• In Pass-Through mode the selected input is passed through to both the (3G/HD/SD)-SDI and HDMI outputs• The DMON-QUAD is a truly portable converter, that incorporates our easy to use LCD and button control system. This gives you easy access to most of the amazing features without using complicated LED/button control, dip switches or having to carry around a computer to change a simple setting• This unit also includes: GPI on RJ-45 connector for Tallies and Remote Switching, RS422/485 on RJ-45 connector for Dynamic UMD and Tallies, USB port for control and firmware updates, Robust Aluminum box, Metal Thread Locking DC Power Socket, Power Supply and HDMI Cable and USB Cable
