DSO112A 2MHz 5Msps 2.4'' TFT LCD Digital Oscilloscope Color Touch Screen Handheld USB Oscilloscope with Test Clip

Description: DSO112A is a pocket oscilloscope with color display and touch panel. What makes DSO112A distinguished among peers is its easy operations, which are all straightforward touching and scrolling. Almost everything is self-teaching. You would not get lost as you might do with other handheld scopes. Designed specifically for students and hobbyists, DSO112A is a great entrance level oscilloscope. With a size that fits right in your hand and pocket, DSO112A can do much more than you might think from its dimension. High sensitivity (2mV/Div) high accuracy, and low noises are highlights of DSO112A and make it a useful tool for small signals probing. TFT color LCD, 1200mAh Li-ion battery (included)... all these add great convenience in use. Features: A pocket oscilloscope with color display and touch panel. 2MHz analog bandwidth and 5Msps Max. real-time sampling rate. Unique rolling slow signal display, the display can be fully continuous signal, unlike SCAN mode will cause the signal display discontinuous. Vertical sensitivity: 2mV/Div, with high accuracy and low noises. Can save 24 groups of preset parameters, save and recall waveform conveniently. Measuring frequency and Max./Min./Vpp/Avg. values of voltage. Adds external triggering function, stronger signal capture ability. PC upload waveform data. Freeze at any time waveform display (HOLD function). Square wave test signal comes 1000Hz/3.3V. Firmware upgradable via Micro USB. Battery/USB powered, built-in smart charger. Specifications: Analog Frequency Bandwidth: 0-2MHz Max. Real-time Sampling Rate: 5Msps Vertical Sensitivity: 2mV/Div-20V/Div Total 12 grades(by way of Progressive 1-2-5) Horizontal Time Base r ange: 1s/Div-50s/Div 21 grades(by way of Progressive 1-2-5) Max. Input Voltage: 50Vpk (100Vpp) Max. r ecord Length: 512/1024 Optional Input Resistance: 1M ohm ADC p recision: 8 Bit Coupling Method: DC / AC Trigger Type: Auto, Normal, Single Trigger Edge: Rising / Falling Edge Trigger Source: Internal / External External Trigger Voltage: 0-15V Time cursors, can automatically calculate and display the time difference Voltage cursors can automatically calculate and display the voltage difference Display: TFT Color Display Power Supply: 3.7V 1200mAh Li-ion Battery(included) / USB Interface Dimension: 68 * 78 * 18mm / 2.7 * 3.1 * 0.7in Weight: 85g / 3.02oz Package Size: 17.5 * 10 * 3cm / 6.9 * 3.94 * 1.18in Package Weight: 201g / 7.09oz >>Please Click Here to Download the English User Manual
