DS1102Z-E 100MHz Digital Oscilloscope 2 Analog Channels 1 GSa/s 24 Mpts UltraVision USB LAN Connectivity Compact Design

Specifications Model DS1102Z EBandwidth 100 MHzChannels 2 analogReal time Sample Rate Up to 1 GSa sMemory Depth Up to 24 MptsWaveform Capture Rate Up to 30 000 wfms sHardware Real time Waveform Recording Up to 60 000 framesDisplay 7 inch WVGA 800x480 TFT LCDVertical Scale Range 1 mV div to 10 V divConnectivity USB HostDevice LAN LXI AUXTechnology UltraVision Trigger Functions Various trigger and bus decodingForm Factor Compact and lightweight Features High Bandwidth 100 MHz analog channel bandwidth and real time sample rate up to 1 GSa s providing accurate and precise signal capturing Extensive Memory Depth Offers up to 24 Mpts memory depth enabling long duration signal storage and detailed waveform analysis Superior Waveform Capture Capture rate of up to 30 000 wfms s and real time recording up to 60 000 frames for in depth diagnostics UltraVision Technology Enhances your measurement experience with intensity graded color display and high resolution waveform details Comprehensive Connectivity Equipped with USB HostDevice LAN LXI and AUX interfaces for easy connectivity and data transfer Package Included 1 x DS1102Z E Digital Oscilloscope1 x USB Cable1 x Power Cord2 x Probes1 x Logic Probe1 x User Manual
