DR55B01 DC 5-24V 2A Flip-Flop Latch Motor Reversible Controller Self-locking Bistable Reverse Polarity Relay Module

DR55B01 DC 5-24V 2A Flip-Flop Latch Motor Reversible Controller Self-locking Bistable Reverse Polarity Relay Module
sku: 1682649
ACCORDING TO OUR RECORDS THIS PRODUCT IS NOT AVAILABLE NOW
$7.99
Shipping from: China
   Description
Feature 1 This is a self locking bistable reverse polarity relay Trigger once output reverse polarity and hold trigger again output input and hold 2 Self locking bistable reverse polarity controller the module can just control forward and reverse start and stop are controlled by power on and power off 3 With power indicator and reverse polarity indicator 4 Low pulse control mode more convenient to use 5 Made of high quality electronic components stable and reliable performanceSpecification Item Type CW CCW Controller ModuleOptional Input voltage DC 5V 5V version DC 6 24V 12V version Module working current forward 2MA reverse 35 40MALoad voltage equal to output voltageLoad current maximum 2A motor 1A With power indicator and reverse polarity indicatorControl mode low pulse controlSize Approx 43 x 21 x 16mm 1 7 x 0 8 x 0 6inWeight 13 5 g 0 5 oz approx Pin Description I power input I voltage input O power output The output in reverse polarity is O power output The output in reverse polarity is G trigger signal ground T trigger signal input 0 2 2 seconds low pulse How to Use Power on the output input press the trigger button Reverse polarity output press again the output input the third press Reverse polarity output and so on Turn off the power and stop outputNote 1 For the module to work stably be sure to use a power supply that is twice the load power If the load is a motor use a power source
