DJI Robomaster S1 STEAM DIY 4WD Brushless HD FPV APP Control Intelligent Educational Robot With AI Modules Support Scratch 3.0 Python Program

Description: Brand: DJI Item: Robomaster S1 Product: Smart RC Robot Battery: 2400Mah Rechargable Lipo Battery APP, Manual, other information: Click here Specifiction: Camera FOV:120 Max Still Photo Resolution: 25601440 Max Video Resolution: FHD: 1080/30fps / HD: 720/30fps Max Video Bitrate: 16 Mbps Photo Format: JPEG Video Format: MP4 Sensor: CMOS 1/4; Effective pixels: 5 MP Operating Temperature Range: -10 to 40 C (14 to 104 F) Narrow Infrared Units: Effective Range [1]: 6 m (in indoor lighting conditions) Effective Area: Varies from 10to 40 Effective area decreases as distance from the target increases. Wide Infrared Units: Effective Range [1]: 3 m (in indoor lighting conditions) Effective Width: 360 (in indoor lighting conditions) Hit Detector: Detection Requirements: For the Hit Detector to be activated, the following conditions must be met: Gel bead diameter 6mm, launching speed 20m/s, and the angle between the hit direction and hit detector plane is no less than 45. Maximum Detection Frequency: 15 Hz DJI Robomaster S1: Weight: Approx. 3.3 kg Dimensions: 320240270 mm (length width height) Chassis Speed Range: 0-3.5 m/s (forward) 0-2.5 m/s (backward) 0-2.8 m/s (sideways) Max Chassis Rotational Speed: 600/s M3508I Brushless Motor: Max Rotational Speed: 1000 rpm Max Torque: 0.25N*m Max Output Power: 19 W Operating Temperature Range: -10 to 40 C (14 to 104 F) Driver: FOC Control Method: Closed-loop speed control Protection: Overvoltage/Overtemperature/Soft-start/Short-circuit/Chip and sensor anomaly detection Control: Controllable Launching Frequency: 1-8/s Max Launching Frequency: 10/s Initial Launching Speed: Approx. 26 m/s Average Load: Approx. 430 Gimbal: Controllable Range: Pitch: -20 to +35/ Yaw: 250 Mechanical Range: Pitch: -24 to +41 / Yaw: 270 Max Rotational Speed: 540/s Vibration Control (on the flat surface): 0.02 Intelligent Controller: Latency (depending on environmental conditions and mobile device): Connection via Wi-Fi: 80-100ms /Connection via Router: 100-120ms (unobstructed, free of interference) Live View Quality: 720p/30fps Max Live View Bitrate: 6 Mbps Operating Frequency: 2.4 GHz, 5.1 GHz, 5.8 GHz Operating Mode: Connection via Wi-Fi, Connection via Router Max Transmission Distance (unobstructed, free of interference): Connection via Wi-Fi: FCC, 2.4 GHz 140 m, 5.8 GHz 90 m CE, 2.4 GHz 140 m, 5.8 GHz 70 m SRRC, 2.4 GHz 130 m, 5.8 GHz 130 m MIC, 2.4 GHz 140 m Connection via Router: FCC, 2.4 GHz 180 m, 5.8 GHz 300 m CE, 2.4 GHz 180 m, 5.1 GHz 100 m SRRC, 2.4 GHz 180 m, 5.8 GHz 300 m MIC, 2.4 GHz 170 m, 5.1 GHz 180 m Transmission Power (EIRP): 2.400-2.4835 GHz FCC: 30 dBm SRRC: 20 dBm MIC: 20 dBm 5.170-5.25 GHz FCC: 30 dBm SRRC: 23 dBm MIC: 23 dBm 5.725-5.850 GHz FCC: 30dBm SRRC: 30dBm Transmission Standard: IEEE802.11a/b/g/n Intelligent Battery: Capacity: 2400 mAh Nominal Charging Voltage: 10.8 V Maximum Charging Voltage: 12.6 V Battery Type: LiPo 3S Energy: 25.92 Wh Weight: 169 g Operating Temperature Range: -10 to 40 C (14 to 104 F) Charging Temperature Range: 5 to 40 C (41 to 104 F) Maximum Charging Power: 29 W Battery Life in Use: 35 minutes (measured at a constant speed of 2 m/s on a flat surface) Battery Life on Standby: Approx. 100 minutes Charger: Input: 100-240 V, 50-60Hz, 1A Output Port: 12.6 V=0.8A or 12.6 V=2.2A Voltage: 12.6 V Rated Voltage: 28 W Gel Bead: Diameter: 5.9-6.8 mm [2] Weight: 0.12-0.17 g [2] App: App: RoboMaster iOS: 9.0 or later Android: Android 5.0 or later Router: Recommended Routers: TP-Link TL-WDR8600; TP-Link TL-WDR5640 (China) TP-Link Archer C7; NETGEAR X6S (International) Supported SD Cards: capacity up to 64GB Recommended outdoor power supply solution for routers: Laptop Power Bank (match the input power of the router)
