DIY XR2206 Function Signal Generator Kit Sine Triangle Square Output 1HZ-1MHZ

DIY XR2206 Function Signal Generator Kit Sine Triangle Square Output 1HZ-1MHZ
sku: 44998
ACCORDING TO OUR RECORDS THIS PRODUCT IS NOT AVAILABLE NOW
$9.85
Shipping from: China
   Description
Feature:Voltage supply: 9-12V DC InputWaveforms: Square, Sine & TriangleImpedance: 600 Ohm + 10%Frequency: 1Hz - 1MHzFrequency, amplitude adjustableFive-digit precision resolutionIt has coarse, fine frequency adjustmentWide range power supply, can use an external power supply 9-12V or 9V batterySINE wave:Amplitude: 0 - 3V at 9V DC inputDistortion: Less than 1% (at 1kHz)Flatness: +0.05dB 1Hz - 100kHzSQUARE wave:Amplitude: 8V (no load) at 9V DC inputRise Time: Less than 50ns (at 1kHz)Fall Time: Less than 30ns (at 1kHz)Symmetry: Less than 5% (at 1kHz)TRIANGLE wave:Amplitude: 0 - 3V at 9V DC inputLinearity: Less than 1% (up to 100kHz) 10mANote: This version does not includes the housing.Package includes:1 x XR2206 Function Signal Generator DIY KitFinished reference picture: Package does not includes the transparent shell.Signal:1MHZ:
