DIY Inverter Boost High Pressure Generator Arc Ignition Lighter Coil Module

Note This is a DIY kit you need to assmble it easy to install no instruction supply Use High school science experiments electronic equipment negative ion generator small scientific production This circuit produces a stable high frequency arc work the temperature is very high can easily ignite combustible material it was called a plasma lighterParameter 10KV transformer outer dimensions is about 20 x 17 x 16mmInput voltage DC 3 7V 7 2V limit 8 4v but is easy to damage so not recommended Input current 1 5AOutput voltage about 20KV please pay attention to safety when using Output current 0 5AHigh voltage pole ignition distance 0 8 cmWarm For reliable long term continuous work it is recommended to use insulating wax or epoxy resin to completely seal the transformer If it is not sealed the transformer will work under no load in air for insufficient breakdown strength of the coil Work prohibited no load Package includes 1 x DIYInverter Boost High Pressure GeneratorNameQuantity1W 47ohm resistance1FR107Fast recovery diode1M3 6 Fixedscrew1Special NPN transistor1Transformer1T 220Insulation film115cm Line1Simple discharge needle For test only 1Aluminum heat sink1
