DHT90 SHT10 Digital Temperature And Humidity Sensor Module Board With Pin

Features: -The series of plug-type temperature and humidity sensors imported SHT series of temperature and humidity sensor chip, pin pin for the standard 2.54mm pin. The sensor quality excellence, the corresponding ultra-fast, anti-interference ability, cost-effective. - Suitable for OEM users, no welding, no water treatment, shorten the development time, improve development efficiency; accurate measurement of relative humidity, temperature, dew point; full calibration output, the use of no need to re-calibration; excellent long-term stability; high-precision two- Interface, directly connected with the microcontroller; request measurement, super energy consumption; no other external components; automatic sleep. Application Areas: This product is suitable for HVACHVAC, Testing and testing equipment, automotive, data logger, consumer electronics, automatic control of weather stations, home appliances, humidity regulator medical phase, building control, environmental monitoring and other measurement occasions. Technical Parameters: Measuring range: 0 ~ 100% RH Temperature range: -40 ~ 120 ° Corresponding time: humidity: 8s, temperature: Resolution: humidity: 0.03% RH, temperature: 0.01 ° Repeatability: humidity: 0.1% RH, temperature: 0.1 ° C Measurement accuracy: ± 4.5% RH, temperature accuracy: ± 0.5 ° (and other precision optional) Hysteresis: ± 1% RH Long-term stability: Installation: 2.54mm pin Package Included: 1 x DHT90 SHT10 Digital Temperature And Humidity Sensor Module
