DG822 Signal Generator Function/Arbitrary Waveform Function Generator 25MHz 2 Output Channels

Features 25 MHz single channel function generatorUpgradeable to two channel via optional software keyTwo channel operation is equivalent to two independent signal sources2 Mpts memory depth upgradeable to 8 Mpts High frequency stability ±1 ppm low phase noise 105 dBc HzBuilt in high order harmonic generator at most 8 order harmonics Built in 7 digits s 240 MHz bandwidth full featured frequency counter160 built in arbitrary waveforms covering common signals in engineering medical and automotive electronics math processing and much moreSample rate up to 125 MSa s vertical resolution 16 bitsArbitrary waveform array editing function available arbitrary waveforms also can be generated through PC softwareVarious analog and digital modulation functions AM FM PM ASK FSK PSK and PWMStandard waveform combine function capable of outputting specified waveforms combined with basic waveformsStandard channel tracking function when enabled all parameters of both channels are updated based on user s configurationsUSB HOST and DEVICE interface standard USB GPIB function supported4 3 TFT color touch screenSpecifications DG800 Series SpecificationsModelDG812DG811DG822DG821DG832DG831Channel212121Max Frequency10 MHz25 MHz35 MHzSample Rate125 MSa sWaveformBasic WaveformsSine Square Ramp Pulse Noise DC Dual toneAdvanced WaveformsPRBS RS232 arrayBuilt in Arbitrary Waveforms160 types of waveforms including Sinc Exponential Rise Exponential Fall ECG Gauss Ha
