DC7-30V Cycle Timer Switch Relay Delay Time Adjustable Cycle Timer Controller Module

DC7-30V Cycle Timer Switch Relay Delay Time Adjustable Cycle Timer Controller Module
Eachine1
sku: 1440491
ACCORDING TO OUR RECORDS THIS PRODUCT IS NOT AVAILABLE NOW
$9.99
Shipping from: China
   Description
Specificatons: Input voltage: 7-30V DC Quiescent current: 4mA Maximum power consumption: 75mA Relay load capacity: 250V 10A AC/30V 10A DC Control mode: automatic cycle and trigger cycle Size: 100x47x29mm Features: 1 Adopt advanced high-quality timing chip control, accurate timing; 2 Use high-power relay to control the load, up to 10A; 3 The relay is turned on and off and the potentiometer is adjustable. 4 delay has potentiometer adjustment, the longer the clockwise adjustment time will be; 5 with a delay switch indication; 6 relay output has normally open and normally closed interface Applications: Application: The module is energized, the relay is simultaneously closed, then disconnected, and the cycle is repeated. It is often used in machine cycle start, stop, product life test, component life test, automation equipment control, PLC control, electronic experiment, etc. Package Included: 1 x Cycle Timer Switch Relay
