DC5V AD8317 Module RF Power Meter Logarithmic Detector Power Controller Signal Amplifier Fm HF VHF

DC5V AD8317 Module RF Power Meter Logarithmic Detector Power Controller Signal Amplifier Fm HF VHF
Eachine1
sku: 1238246
ACCORDING TO OUR RECORDS THIS PRODUCT IS NOT AVAILABLE NOW
$32.99
Shipping from: China
   Description
Descriptions 1 Supply voltage 5V DC typical current 20mA 2 The input signal dynamic range 55 dBm to 0dBm3 module supports change detection slope and power measurements the controller two kinds work types 4 Bandwidth 1MHz to 10GHz5 shielded with a metal housing6 the input impedance 50 ohms Product application Analog Device Inc Adi D I A released before the radio frequency F R log detector and controller D A 8317 The device can accurately measure the F R signal power of all cellular standards and a variety of wireless infrastructure as well as the frequency range of broadband wireless applications in 10G H Z 1MHz In addition the device provides fast output response can be more effective to complete the F R burst detection which is packaged as m 3ra x m 2ra AD8317 demodulating logarithmic amplifier provides precise R f measurement and dynamic state the scope of the measurement accuracy of better than 1 dB at the greater than 50dB Output end with adjusting a power amplifier and a variable gain amplifier with power controller function The wide operating frequency range of H Z 1M to H Z 10G supports all of the Cellular standard S M C D M A W D D M A C T S C D M A G broadband wireless standard 802 16 IM A X W IB R O W and private systems operating in various frequency bands AD8317 in a 40 C 85 C temperature range to provide better precision temperature stability and has a fast 5ns output response which can achieve more than 12 Z
