DC12V Pneumatic Aluminum Electric Solenoid Air Valve 5 Way 2 Position Valve 4V210

Description DC12V Pneumatic Aluminum Electric Solenoid Air Valve 5 Way 2 Position Valve 4V210Specification MaterialAluminum alloySize11 7x5 8cm 4 6 2 3 inchTypeNC NOVoltageDC12VPower consumption4 8W　ActionDirect actingType5 Port 2 positionLubricationNot requiredPressure range0 1 0MPa 145psi Insulation F ClassProtectionIP65Voltage range 15 10 Temp range 5 60℃Max frequency10 cycles sMin activate time0 05second Features Appearance commutation good performance Automatic compensation for seal wear Use of long life NOTE When installing please note that the gas flow direction is correct and takeoverWhen using strict compliance with the technical requirements such as operating voltage operating frequency operating pressure temperature when the machine commissioning it is recommended to use the manual device debugging and then power test Attention to dust it is recommended to install exhaust outlet muffler or silencer throttle When connecting pipe pay attention to only release the strap around the joint may not exceed the end face of the tooth and payattention to the elimination of pipe fittings metal particles inside the pipe dust and oil mist Package Included 1 x Pneumatic Solenoid Air ValveMore Details
