DC 6V-30V 12V 24V PWM Motor Speed Controller Digtal Display Max 8A 16kHz Adjustable DC motor Control CV Governor Switch

Features CCM5D DC Motor Speed Regulator controls the speed of a DC motor by adjusting Pulse Width Modulated PWM Large 0 56 inch 3 digit LED display numbers allow viewing under the most adverse conditions The display range of 3 digit LED display is 000 100 For example displayed 066 as the picture 1 it means that the PWM output duty cycle is 66 Input supply voltage range is 6V 30V DC PWM frequency is 16kHz Adjustable speed range is 0 100 Suitable for the DC motor or DC load within 5A Peak current 8A Item size 80 x 42 x 24mm Operating Instruction 1 Connect wires refer to the wiring diagram NO 4 picture 2 Turn on the power and adjust the potentiometer 3 The LED display displays the PWM output duty cycle 4 Push the key the controller closed push it again the controller open Warning 1 Before you attempting to wire the controller make sure power is off 2 Do not reverse the negative and negative supply loads This can damage the controller 3 Change the direction of the motor and exchange the positive and negative poles of the motor Package Include 1 x Adjustable Motor PWM Speed Controller with Digtal Display
