DC 5V Real time Timing Delay Timer Relay Module Switch Control Clock Synchronization Multiple mode Control

Module parameter Wide voltage power supply 5 0V 60V One mode can set multiple time periods up to 5 time periods With buzzer alarm function Mode introduction OPE Relay closing time CLE Relay opening timeTime period PE 1 to PE 5 5 time periods function shieldP 1 Every day OPE relay is closed output pulse CLE relay is disconnected output pulseP 2 OPE relay closed pulse output on the same day CLE relay disconnected pulse outputP 3 What day of the month and day OPE relay closed output pulse CLE relay disconnected output pulseP 4 From what day of the month to what day of the month what time every day starts and ends at what time OPE relay is closed output pulse CLE relay is disconnected output pulseP 5 From what day of the month to what day of the day what time starts and ends at what time OPE relay is closed output pulse CLE relay is disconnected output pulseNote Stop time date CLE start time date OPE In the time to run the interface press the DOWN button for a while Step 1 Select the time period PE 1 PE 5 Press UP and DOWN to select Step 2 Press the SET key to select the mode P 1 P 5 Set this time period to the corresponding mode by pressing the UP and DOWN keys means to block this time period Note Each time period can be repeated from the P 1 P 5 one of the optional For example you can let five time periods at the same time work in the P 1 mode or let Time period 1 work in P 1 mode time period 2 work in P 2 mode and so
