DC 3-36V 15A Peak 30A PWM DC Dual Channel Motor Driver Board Industrial Grade High Power H Bridge Control Module Strong

DC 3-36V 15A Peak 30A PWM DC Dual Channel Motor Driver Board Industrial Grade High Power H Bridge Control Module Strong
Peak
sku: 1255708
$22.30-24%
$16.99
Shipping from: China
   Description
Specifications Rated voltage DC 3V 36VRated current 15APeak current 30ASize 108 x 58mmMotor forward DIR 1 PWM PWMMotor reverse DIR 0 PWM PWMParking brake DIR X PWM 0 X is any state Connnection POWER connects with power positive GND connects with power negative 2 motors respectively connect with MOTOR 1 MOTOR 2 Applications for DC motor control circuitFeatures The drive uses the full two half bridge driver chip low resistance N channel MOSFET components Complete two half bridge driver chip reliable drive mode the MOSFET switching losses to a minimum Improve power utilization MOSFET driver chip comes with hardware brake function and power feedback N channel MOSFET IRF3205 MOSFET use two dedicated half bridge driver chip on the top tube using the bootstrap capacitor so that the tube has enough drive voltage of the MOSFET channel can be opened quickly improve motor acceleration curvature but also quickly for the motor brake This allows the trolley can quickly start can quickly kill the car The driver can operate at 0 99 of the duty cycle of the PWM modulation the motor drive voltage can be obtained sufficiently Package included 1 x DC dual channel motor driver board
