DC 12V-36V 500W PWM Hall Motor Balancing Brushless Motor Controller Automotive Balanced BLDC Car Driver Control Board
Description
Parameter Operating voltage 12V 36VOperating current ≤15ADriving power ≤500WSpeed regulation voltage 0 1V 5VOperating temperature 40 85℃Operating temperature ≤90 RHOvercurrent protection YesBlocking protection YesDirection control YesTo enable to control haveSpeed signal YesApplication 1 Confirm that the voltage and power parameters of the motor not exceed the range as specified 2 Applicable to hall brushless dc motor with Hall at 120° not all manufacturers Hall line order are corresponding you can adjust the Hall line order or motor three phase line order according to the actual situation to achieve the best driving effect 3 JYQD V7 3E2 is driver board without housing and heatsink it can drive the motor below 100 watt without any heatsink but needs normal ventilation 4 The 5V output port on the drive board is forbidden to connect external power equipment It is only applicable to external potentiometer or switch for speed adjustment commutation and enabling operation 1 Control port5V Driver board internal output voltage external potentiometer or switch for speed adjustment and reversing operationZ F Rotating direction control ports Connect 5V high level or no connect is Forward direction connect 0 V low level or connect to GND is reverse direction VR Speed control port Analog voltage linear speed regulation 0 1v 5V The input resistance is 20K Ohm connect with GND when input PWM speed regulation PWM frequency 1 20KHZ Duty cycle 0 100 EL
