DC 12V 10A 1CH 433MHz Relay Wireless RF Remote Control Switch Receiver With Transmitter

Specification: Receiver 1.Input Voltage: DC10-14V 2.Standby Current: 90dBm 6.Remote Control Distance: >100 meter(In open environment) 7.Decoding Way: MCU Software decoding 8.Can store the number of remote control:50 9.Support remote control type: Fixed code, learning code 10.Channel: 1CH 11.Multiple working modes: (Jog/Non-Latched ,inter-lock/Latched ,self-lock /Self-Latched,Delay off) 12.Wiring Method:Fixed wiring terminal 13.Working Voltage: DC12V 14.Output Current: 10A 15.Rated load:10A 250VAC / 10A 125VAC 10A 30VDC / 10A 28VDC 16.Output:Normally open,Common,Normally closed 17.Dimension:3.5cm*3cm*1.6cm Transmitter 1.Material:ABS Plastic 2.Battery:23A Battery (Battery is not included) 3.Operating voltage: 12V 4.Frequency: 433MHZ 5.Reference distance: 150 meters (This is the theory distance in open environment without interference, practical application due to the interference environment and decreased) 6.Current job: 9 ~ 12mA 7.Transmitting power: 10-15mw 8.Frequency deviation: 0.2MHz 9.Size (LxWxH): 58x38x15 (mm) Working/output way: 1.Jog/Non-Latched: Press one button is Working /ON. Loosen your finger on the same button is Stop/OFF. One channel switch need one buttons remote control. 2.Self -lock/Self-Latched: Press one button for one time is working/ON. Press the same button again is stop/OFF. One channel switch need one buttons remote control. 3.Inter-lock /Latched: Press one button is working/ON, press another button is stop/OFF. One channel switch need 2 buttons remote control. 4.Delay: Press remote control relay pull-in,release the remote control and begin timekeeping,after 5s,10s,15s will automatically close the relay Description: 1. press the learning code .the indicator flash ,loosen your finger ,press any button of the remote control the indicator flash 2 times and off .it mean you learn it successfully . 2. it can learn more than 12 PCS 2262 or 1527 chip with the different code wireless 433MHz remote control 3. remove/clean :press the learning button about 8 seconds the indicator turn on to off, it means the information that you keep have been removed successfully . Package included: 1 x 12V 1CH 433MHz Wireless Relay Switch Receiver 1 x 433MHz Wireless Remote Control (Battery is not included)
