DC 10-60V 12V 24V 48V 20A PWM DC Motor Speed Controller Soft Start Switch TE1255 775 Motor

Feature Soft start Can solve the damage caused by instantaneous high current to speed controller Blocking protection 20A current limited Limit the high current produced by the blocking of the motor Panel switch control more easy to control the speed for the projectSpecification Input voltage DC 10 60A The specific voltage must be the same as the rated voltage of the motor Output voltage Linear output under loadSupport motor DC brush motorOutput current Max 20A Limited value 20A Continuous working current within 18AMax power 240WRegulating type regulating currentRegulating method potentiometer 270° linear Regulating speed range 0 100 Control frequency 15KHZKnob 10K with switch Size 95mm 60mm 32mmPanel mounting 88mm 55mmPackage Included 1 x DC 10 60V 20A PWM DC Motor Speed Controller
