DANIU DSO188 Pocket Digital Ultra-small Oscilloscope 1M Bandwidth 5M Sample Rate Handheld Oscilloscope Kit

Description : DANIU DSO188 is a super small digital oscilloscope with 5MS/s sampling rate and 1MHz bandwidth is designed for electronic enthusiasts and circuit R & D maintenance personnel. 1MHz bandwidth can be used for an amplifier, oscillator, automatic control system, DC/DC, inverter, switching power supply and so on. Whether DIY or scientific research education, vehicle maintenance, household appliances maintenance and so on are all good choices. Features : Memory compression technology, waveform refresh screen does not flicker. 1.8-inch color display screen. 1MHz analog bandwidth and 5MS/s sampling rate. High measurement voltage range, 1X can measure 0-40V, 10X can measure 40-800V. Frequency can be displayed, Vmax, Vmin, Duty, Vrms, Vpp. At any time, the waveform display (pause function) is frozen. Battery/USB power supply, built-in 250mAh battery and intelligent charge management. Ultra small volume, easy to carry. Specification : 1. Analog band width: 1MHz 2. Maximum real time sampling rate: 5MS/s 3. Vertical sensitivity: 50 mV/div-200 V/div 4. Horizontal time base range: 100mS/div-2uS/div 5. Maximum input voltage: 40 V (1X probe) 800 V (10X probe) 6. Storage depth: 40KB 7. Input resistance: 1M 8. ADC precision: 12bits 9. Coupling mode: AC/DC 10. Trigger mode: Auto 11. Trigger edge: Ascending/descending edge 12. External trigger voltage 0-40V 13. Display: TFT color display 14. Power supply: 250 mAh lithium battery 15. Size: 57 x 34 x 11 mm 16. Weight: 40 grams Package includeds : 1 x DANIU DSO188 oscilloscope host 1 x Oscilloscope probe 1 x BNC turn MCX switch head 1 x Micro USB data line 1 x English User manual >>Please Click Here to Download the English User Manual
