DAC0832 DIY Module Kits DAC Waveform Generator Unipolar Bipolar Outputs Electronic Component

Description: Module size: 4cm x 4.9cm Supply voltage: 15V The right of the pin: + VIN: positive power supply 15V GND: power supply ground -VIN: Negative 15V power supply OUT2: bipolar output port OUT1: unipolar output port Pin the left: CS: Chip Select, received a single-chip IO, active low; WR: write, received microcontroller IO, active low; D0-D7: 8-bit parallel data port, received a single-chip IO; GND: GND Module 5V: 5V output module Intermediate: JP1 shorting cap to select the reference voltage VREF, If you put the shorting cap, VREF module is 5V; if you remove the shorting cap, VREF can own their own external input to a reference voltage Package Included: 1 x DIY Module Kits DAC Waveform Generator
