Cergrey Body Induction Module 15m Microwave Sensor Module For Business Industries

Features: Non-contact detection moving object detecting. This module s transmitting frequency is 24GHZ can be widely applied in business industries word controlling etc. Provide various frequency range standards: -UK -F. Advanced low consumption PHEMT oscillator. Independent transmitting and receiving route can get the big gain. High sensibility high flexibility low cost operating distance is 15m. Single channel operation. Specifications: Transmitting Frequency: min:24GHz typ:24.125GHz :24.25GHz Output Power:16dbm (typ) Antenna pattern: horizontal direction: typ.80 vertical direction: typ.32 Side lobe suppression ratio: horizontal direction: typ.13dB vertical direction: typ.13dB Operating Temperature:-20~60℃ Operating Current: typ:30MA :40MA Operating Voltage: typ:5.5V Pulse Width: typ:10US IF Output:-300~300MV Size: 25 x 25 x 7mm/0.98 x 0.98 x 0.27inch Weight: 5g Package Included: 1 x Microwave Body Induction Module
