CTE TFT/SD Card Shield Expansion Board for Arduino MEGA 2560 LCD Module SD Card 2.8 3.2 Inch

CTE TFT/SD Card Shield Expansion Board for Arduino MEGA 2560 LCD Module SD Card 2.8 3.2 Inch
thumb
thumb
thumb
thumb
thumb
thumb
thumb
thumb
thumb
sku: E5083
ACCORDING TO OUR RECORDS THIS PRODUCT IS NOT AVAILABLE NOW
$10.39
Shipping from: China
   Description
Features:
True 5V to 3.3V level translation using TI SN74ALVC164245 for LCD data lines, TI SN74LVC4245 for LCD control line and SPI lines.
Highest compatibility, one shield for many types of TFT LCD modules.
Drive TFT LCD for Arduino DUE by just plugging into Arduino MEGA 2560 main board, no flying wires.
Compatible with 32-pin version LCD, which is commonly used in STM32 development board.
On board SD card slot.
On board SPI flash footprint with adjustable CS selection, for upgrade to include Font IC to draw text to the LCD and also support for SPIFlash library.
This shield has a onboard 1A 3.3V regulator to supply enough current to the screen.
LCD power 3.3V and 5V selectable through solder jumpers.
LCD Backlight (LEDA+) 3.3V., 5V or PWM selectable through solder jumpers.
The shield is compatible for Arduino MEGA 2560 and the following LCD:
2.2 TFT LCD module (220x176)
2.8 TFT LCD module (320x240)
3.2 TFT LCD module with font IC (320x240)
3.2 High Resolution TFT LCD Module with font IC (480x320)
3.5 TFT LCD module with font IC (480x320) (full viewing angle IPS panel)
4.0 TFT LCD module with font IC (480x320)
4.3 TFT LCD module with font IC (480x272)
5.0 TFT LCD module with font IC (800x480)
7.0 TFT LCD module with font IC (800x480)
