CTE TFT LCD / SD OLED Card Shield For DUE Support 32Pin 40Pin Version LCD

Description Now you can drive TFT LCD in a much faster speed using 84Mhz Ardiuno DUE The shield is designed to fit two types of LCD 1 40pin version LCD which is commonly used in previous version of TFT Mega shield for MEGA 25602 32pin version LCD which is commonly used in STM32 development board unsoldered The shield route all the LCD data pins to port PC1 PC8 and PC12 19 control pins to PD0 PD3 this design can acheive high speed data transfer three cycles per write strobe to the LCD to maximize LCD display speed The SPI interface for SD or flash control is route to the ISP header of DUE so that high speed SPI transfer with DMA can be achieved The shield is compatible with DUE and the following LCD 2 2 TFT LCD Module 220x176 2 8 TFT LCD Module 320x240 3 2 TFT LCD Module with Font IC 320x240 3 2 High Resolution TFT LCD Module with Font IC 480x320 3 5 TFT LCD Module with Font IC 480x320 Full viewing angle IPS panel 4 0 TFT LCD Module with Font IC 480x320 4 3 TFT LCD Module with Font IC 480x272 5 0 TFT LCD Module with Font IC 800x480 7 0 TFT LCD Module with Font IC 800x480 Features Drive TFT LCD on DUE by just plugging into DUE main board no flying wires Compatible with 40 pin version LCD which is commonly used in TFT Mega shield Also comptabile with 32 pin version LCD which is commonly used in STM32 development board On board SD card slot with adjustable CS selection On board SPI flash footprint with adjustable CS selection for upgrade inclu
