CJMCU-3935 AS3935 Flash Sensor Strike Detection Storm Distance Module

Description: The AS3935 is a programmable fully integrated flash sensor IC that detects the presence and approach of potentially hazardous flash activity in the vicinity and provides an estimation on the distance to the head of the storm. The embedded flash algorithm checks the incoming signal pattern to reject the potential man-made disturbers. The AS3935 can also provide information on the noise level and inform the external unit(e.g. microcontroller) in case of high noise conditions, with the noise floor generator and noise floor evaluation blocks. The AS3935 can be programmed via a 4-wire standard SPI or an IIC. Also, in case the latter is chosen, it is possible to choose among four different addresses. Two clocks are internally generated by two different RC-Oscillators: TRCO and SRCO. An automatic procedure can increase the precision of those oscillators. The AS3935 can be either supplied by an internal voltage regulator or directly by VDD. Feature: Flash sensor warns of flash storm activity within a radius of 40km Distance estimation to the head of the storm down to 1km in 14steps Detects both cloud-to-ground and intra-cloud(cloud-to-cloud) flashes Embedded man-made disturber rejection algorithm Programmable detection levels enable threshold setting for optional controls SPI and IIC interface is used for control and register reading Antenna turning to compensate variations of the external components Supply voltage range: 2.4-5.5V Power-down, listening, and active mode Package: 16LD MLPQ(4x4mm) Applications: AS3935 is ideal for Weather Stations, Clocks, Sports Equipment, portables, Pool Safety, Uninterruptible Power Supply(UPS) Global Positioning System(GPS) Cellular phones, Watches, and Golf Equipment. Package included: 1 x CJMCU-3935 AS3935 Flash Sensor Module
