CC3D Flight Controller 8Pin Connection Cable Set ReceiverPort for for RC Drone FPV Racing Multi Rotor

CC3D Flight Controller 8Pin Connection Cable Set ReceiverPort Description: Item name: CC3D Cable Set Color Function JST-SH Pin Servo connector plug Black Ground 1 1 Red Power to RC RX-(VCC Unregulated) 4.8V-15V 2 1 White PWM signal 1 or combined PPM 3 1 Blue PWM signal 2 4 2 Yellow PWM signal 3 or PWM output channel 7 5 3 Green PWM signal 4 or PWM output channel 8 6 4 Orange PWM signal 5 or PWM output channel 9 7 5 Purple PWM signal 6 or PWM output channel 10 8 6 S.BUS Black 1 GND GND GND GND Red 2 4.8V-15V PWR out (VCC unregulated) PWR out (VCC unregulated) PWR out (unregulated star) Blue 3 3.3V TX SCL Orange 4 3.3V (5V Tolerant) RX SDA TX (signal) Package included: 1 x CC3D Cable Set
