C8051f330 C8051F330D Development Board Learning Experiment Programmer MicroController C8051F Mini System Development Boa

C8051f330 C8051F330D Development Board Learning Experiment Programmer MicroController C8051F Mini System Development Boa
sku: 1660579
ACCORDING TO OUR RECORDS THIS PRODUCT IS NOT AVAILABLE NOW
$18.99
Shipping from: China
   Description
 Manual Click here to open Chip Features C8051F330D is the best choice for getting started with C8051F series MCU On the basis of learning the basic STC89 series 51 MCU and AT or AVR MCU choose the enhanced C8051F series MCU is your best choice 1 8051 compatible CIP 51 core with high speed and pipeline structure up to 25MIPS 2 Full speed non intrusive in system debugging interface on chip 3 True 10 bit 200ksps 16 channel single ended differential ADC with analog multiplexer 4 10 bit current output DAC 5 High precision programmable 25MHz internal oscillator 6 8KB of 768 bytes of on chip RAM that can be programmed in the FLASH memory of the system 7 SMBus I2C enhanced UART and enhanced SPI serial interface implemented by hardware 8 4 general 16 bit timers 9 Programmable counter timer array PCA with 3 capture compare modules and watchdog timer function 10 On chip power on reset VDD monitor and temperature sensor 11 On chip voltage comparator 12 17 port I O allow 5V input Development Board Features 1 C8051F330 can be evaluated F330D is in line F330 is QFN package 2 All resources of C8051F330 are open to users connector mode 3 Can test all resources in C8051F330 4 Onboard 1 4 bit LED serial reality 595 2 Buzzer 3 Dual channel AD acquisition 4 RS232 interface 5 TFT LCD screen interface 6 Wireless module interface 7 JTAG emulator interface 8 Lead out all IO ports to facilitate experiment and test 9 MINI usb power supply
