Blackmagic Design Cloud Store Mini, 16TB
Blackmagic Cloud Store Mini lets you share your media files globally, eliminating the high cost of collaborating with talented editors and colorists around the world! Blackmagic Cloud Store Mini is storage that syncs and shares media with Blackmagic Cloud, Dropbox and Google Drive.
It even understands proxy workflows, so a whole timeline and its media can be shared in minutes. The internal memory core is so fast it can saturate the 10G Ethernet port to its theoretical maximum speed, even with multiple users connected. File access is very low latency, so responsiveness is fast. That means it's perfect for sharing large media files between editors, colorists, audio engineers and VFX artists!
Designed for Film and TelevisionBlackmagic Cloud Store Mini is the perfect network storage solution for any use! It's great for film and television where large media files need to be shared between multiple users for editing, color correction, audio post and VFX work. It even handles massive 12K Blackmagic RAW digital cinema files! Each user gets zero latency and they don't need to store files on their local computer.It's the perfect solution for DaVinci Resolve! Blackmagic Cloud, Dropbox and Google Drive sync allow multiple disks to be synchronized in different locations globally. Then each location gets the fastest editing experience possible. That's critical for multicam editing where multiple media files are playing simultaneously!Larger capacity model features 16 TB capacity, as well as RAID 0 flash memory core, 10G Ethernet, 1G Ethernet, USB-C, Dropbox and Google Drive sync for distributing files globally.
Portable and Quiet Design
Blackmagic Cloud Store Mini features a compact rack mount design that's very portable and whisper quiet. Internally it has an array of 4 flash memory cards working in parallel for higher speed. The 10G Ethernet port and the 1G Ethernet port operate as a 2 port network switch. That's great if you don't have a 10G Ethernet network, as you can connect the 10G port directly into your computer and the 1G port to your existing network. If you need to access files quickly, then the USB-C even operates as a network connection, simply by plugging it into your computer. There is also an HDMI monitoring output so you can watch a live graphic view of the storage operating on a TV or monitor.
Flexible Power
An IEC power socket is included for connecting AC power. All international AC voltages are supported so you can use it globally. Plus there is a separate DC power input for redundancy or battery use.
10G EthernetThe 10G Ethernet port allows high speed computers to be connected. It's fast, even when lots of users are connected at the same time. It's perfect for connecting to the latest 10G Ethernet switches.
1G Ethernet
The 1G Ethernet connection is provided for slower connections such as the internet or slower computers. It is part of the built in Ethernet switch and helps keep the faster 10G port free.
USB-C ConnectionThe USB-C port supports Ethernet for connecting it to your computer to access files. That's possible because there is a USB-C to Ethernet adapter built in! USB-C is also used for settings and updates.HDMI Monitor Output
The HDMI monitor output lets you see the status of your Cloud Store Mini in real time. Simply plug in a TV or monitor. You can see a storage map, speed graphs, sync, active users and power status!
Flash Memory Allows Multiple Simultaneous Users
Blackmagic Cloud Store Mini models have either 16TB of flash memory, so you have lots of space for your files. That's fantastic for television production, as it's small enough to be portable, but it has enough storage space for lots of video media. M.2 flash memory cards are used for extreme reliability, high access speeds and zero seek times.
Plus the four M.2 cards are arranged in a parallel RAID 0 group so they can operate much faster than a single card. That ensures enough speed to keep up with the 10G Ethernet connection. Plus in the future, as new larger M.2 cards are released, the flash memory cards can be replaced with new ones. That ensures a very long life!
High Performance for Digital Film FilesWith a separate very high speed 10G Ethernet connection, Blackmagic Cloud Store Mini is very fast. The internal memory core has been designed to saturate the 10G Ethernet port to its theoretical maximum speed, even with multiple users connected. It's so fast, most computers cannot keep up! Plus file access is very low latency, so responsiveness is fast.
That's possible because of the parallel processing used by the memory core. Even at maximum speed, the Blackmagic Cloud Store Mini is extremely quiet with very little cooling fan noise. Even when editing large 12K digital film RAW files. It's so fast, multicam editing is very smooth, even if it's used with large digital film camera files!
Sync to Blackmagic Cloud, Dropbox or Google Drive
Now you can set up a local cache of your Blackmagic Cloud, Dropbox and Google Drive files! This makes working much faster because files are instantly available without needing to be downloaded from the internet. Blackmagic Cloud Store Mini will constantly work to stay in sync. You can save space on your computer by moving cached Dropbox and Google Drive files to the Blackmagic Cloud Store Mini so everyone on your network can share them.
You can even sync multiple Blackmagic Cloud Store Minis via Blackmagic Cloud, Dropbox and Google Drive so people in different geographic locations can collaborate without latency because everyone has a local copy of the files. Blackmagic Cloud, Dropbox and Google Drive are also fantastic backup solutions!
Add Cloud ServiceMake sure your Blackmagic Cloud Store Mini is connected to the internet. Enter your Blackmagic Cloud, Dropbox or Google Drive account details, so the Cloud Store Mini can gain access to allow sync.
Set Sync Folders
Next you need to set the sync folders. That tells the Blackmagic Cloud Store Mini where to sync its files to the remote Dropbox or Google Drive account. You can also have multiple sync folders!
Set Sync DirectionNow set the sync direction. One direction is good when you have local files you want to share, but not enough room for everyone's files. Both directions means everyone gets the same set of files.
Distribute Files Globally
With support for Blackmagic Cloud, Dropbox and Google Drive sync, you can use multiple Blackmagic Cloud Store Mini units to share files globally. That's important when working with large datasets or massive digital film and video files. As these files are accessed dozens of times a second, so most internet connections are too slow to handle it.
While the internet has too much latency to access large files remotely, you can use it to sync these files. Syncing the files to local storage totally eliminates delays in accessing them. That's because everyone has a local copy of the files on their network. Blackmagic Cloud Store Mini will constantly sync files, even if your computer is turned off!
Real Time Monitoring
The most exciting feature is the HDMI monitoring output! Simply connect a TV or computer monitor to get a live status of the Blackmagic Cloud Store Mini. The storage map shows a graphic representation of the memory core and real time read and write access for the connected users. It's quite mesmerizing to watch! There are also graphs that show you the data transfers on the Ethernet connections.
The main space indicator shows you the capacity of the memory core and how much is currently being used. You can also add a custom name to the store! The status for each Blackmagic Cloud, Dropbox and Google Drive connection is also shown. You can even see connected users and the power supply status.
Usage IndicatorOn the top left you can see the storage capacity indicator. The number on the left is the space used and the number on the right is the total memory capacity of Blackmagic Cloud Store Mini.
Customizable Name
You can give a custom name to the Blackmagic Cloud Store Mini so you can identify it on the monitor display and the utility software. To change the name, just use the Blackmagic Cloud Store utility!
Storage Map
The storage map display shows a view of the memory core. The memory is divided into segments with reads in cyan and writes in orange. With lots of connected users, the display gets exciting to watch!
Cloud Sync StatusThe cloud sync status shows each sync folder and transfers to and from Dropbox and Google Drive. When new files appear in any sync folder, you can see the transfer status as they sync!
User Connections
You can see each of the connected users and the data transfers for each. However, this list will move down if you have more cloud sync folders as the sync folder status is more important!
Cloud Store Mini Status
The bottom left is the hardware status. This includes the power status for the AC and DC power supplies. Plus if there are any internal service issues, they will be displayed here.
Speed Graphs
The lower part
