Beitian BS-70N GPS+GLONASS Dual GPS Module 5V Input TTL Level W/ 2m Cable for RC Drone FPV Racing

Beitian BS-70N GPS+GLONASS Dual GPS Module 5V Input TTL Level W/ 2m Cable for RC Drone FPV Racing BS-70N datasheet, please click here. Specification: Item name: Beitian BS-70N GPS+GLONASS Dual module Dimensions: O=56mm*18mm Weight: 100g Connector: 4 Cable: Red VCC, Green RX, White TX, Black GND Cable Length: 2.0m Fixed: Magnetic bottom Built-in TLL level, 9600, 1Hz output, NMEA-0183 protocol output Electrical Characteristics Chipset: G7020-KT Frequency: GPS L1, SBAS L1, QZSS L1 Receiving Format: GPS, SBAS, QZSS Channels: 56 Searching Channel Sensitivity Tracking: -162dBm Reacquisition: -160dBm Cold Start: -148dBm Accuracy Position Horizontal: 2.0 m (Typical Open Sky) Velocity: 0.1m/sec 95% (SA off) Timing: 1us synchronized to GPS time Acquisition Time Cold Start: 29s Warm Start: 25s Hot Start: 1s Data Output Support Rate: 4800bps to 921600bps, Default 9600bps Data Level: USB, TTL, RS-232 Level. Default TTL level Data Protocol: NMEA-0183 or UBX, Default NMEA-0183 NMEA Message: RMC, VTG, GGA, GSA, GSV, GLL Update Rate: 1Hz-10Hz, Default 1Hz FLASH: 4M FLASH, Store the configuration permanently Operational Limits Altitude: 50,000m Max Velocity: 515m/s Max Acceleration: Less than 4g Power Consumption VCC: DC Voltage 3.0V-5.5V, Typical: 5.0V Current: Capture 45mA@5.0V Environment Operating Temp: -40 C ~ +85C Storage Temp: -40C ~ +105C Package included: 1x Beitian BS-70N GPS+GLONASS Dual module
