Behringer Ultracurve Pro Ultra-High Precision Digital Loudspeaker Management System, DCX2496, Black/Silver

Highlights: The DCX2496 Ultracurve Pro from Behringer is a digital loudspeaker management system, that provides excellent audio quality, along with a comprehensive feature list. It allows for precise set-up of multiple loudspeaker arrays, suitable for live sound, fixed installations that require control of loudspeaker systems, and other contractor-installed applications. Each of the three-inputs and six-outputs have fixed processing blocks, including gain, delay, EQ and dynamic EQ on the input channels, and gain, crossover, EQs, limiter and delays on the output side. One of the inputs can accept a stereo AES/EBU digital signal. An integrated sample rate converter assists in accepting various sample rates. Additionally, an internal input-sum signal is easily set-up. Four different mono and stereo output operating modes are available, all with individual crossover filter types with selectable roll-off characteristics. Input and output delays allow for time adjusting signals to compensate for ambient temperature changes or for adjusting arrival time differences for individual speaker clusters. EQs can be used for both musical enhancement or for level-dependent equalization. Brick-wall limiters guarantee speaker protection. 3 analogy inputs (one suitable as digital stereo AES/EBU input) and 6 analogy outputs for maximum flexibility High-end 96 kHz converters for ultimate signal integrity and wide dynamic range (120 dB) Integrated sample rate converter for easy connection of external digital signals with sampling rates from 32 to 96 kHz Precise Dynamic EQs for level-dependent equalization and extremely musical Parametric EQs, selectable for all inputs and outputs Several types of EQs (LP/BP/HP) for each input and output "Zero"-attack Limiters on all output channels for optimal speaker protection Four different mono and stereo output operating modes Individual crossover filter types (Butterworth, Bessel and Linkwitz-Riley) with selectable roll-off characteristics from 6 to 48 dB/octave Adjustable Delays for all inputs and outputs? Allow manual or automatic correction for room temperature, phase and arrival time differences Additional Sum signal derived from the A/B/C inputs offers a fourth internal input signal Free ULTRADRIVE PRO software enables total control via PC through RS-232 and RS-485 interfaces Link option via RS-485 network interface enables cascading of several Ultra drive PROs 60 user-defined internal presets storable Servo-balanced, gold-plated XLR connectors for all inputs and outputs Internal switch-mode power supply for maximum flexibility (100 - 240 V~), noise-free audio, superior transient response plus low power consumption for energy saving 3-Year Warranty Program* Designed and engineered in Germany
