BMS 7S 50A 3.7V Ternary Lithium Battery Protection Board with NTC Temperature Sensor

Specification NumberItemStandardsUnitMINTypicalMAX0informationRated working voltage B B 30VRated discharge current 2530APeak starting current 60 A1OverchargeprotectionP P input withstand voltage40VCharging overcurrent protection value not limited ACharging detection voltage4 2004 2254 250VCharge detection delay time0 511 3Sovercharge release voltage4 0004 0054 050V2Over discharge protectionDischarge detection voltage2 6502 7002 750VDischarge detection delay time20100150msDischarge release voltage2 852 953 05VRotection release conditionDisconnect external load or charge self recovery3Overcurrent protectionOvercurrent detection voltage 0 1 VOvercurrent protection current202325AOvercurrent protection time0 711 3SProtection release conditionDisconnect external load or charge self recovery4Short circuit protectionShort circuit protection current 40 A Detection delay time150250400uSProtection release conditionDisconnect external load or charge self recovery5Internal resistanceMain circuit on state resistance 910mΩ6Current consumptionNormal operating current consumption 1015uA7Quiescent CurrentCurrent consumption during sleep2 5uA9Operating temperature 402585℃10 physical dimensionL60 x W23 x T5nmmmPackage included 1 x 7S 50A BMS Battery Protection Board with NTC
