BCLONG 4S 30A 14.8V Li-ion Lithium Battery Protection Board Battery Equalizer Board

Specifications: Product Name: Battery Protection Board Color: Green Over charge detection voltage: 4.28V Over charging voltage: 4.095-4.195V Over discharge voltage: 2.55+0.08 Over charge detection delay time 0.1s Temperature range -30-80 Short circuit detection delay time: 100ms Over current detection delay time: 500 ms Balanced current:60mA Working current: 30A Over current: 60A Short circuit protection function: there is disconnect the load can be self recovery Size:45x56mm Quantity: 1pc Main function: Over charge protection over discharge protection function short circuit protectionfunction over current protection function balance Interface definition: Charging port of the plate and the discharge port is the same both positive and Bconnecting battery - P- charging port and port on the negative electrode;B- N- P- pads are all over the hole the hole diameter of the pad is 3.5mm;The battery charging detection interface with DC output in the form of needle. Do thesame mouth when the N- is not wiring. Please note: The lithium battery protection board cannot be used for lithium iron phosphate batteries electric drill battery packs electric fish machine battery packs electric bicycle battery packs children s car batteries power motors above 550 and 1W fisheye LED lights. Package Included: 1 × Protection Board Note: 1.Transition: 1cm=10mm=0.39inch. 2. The real color of the item may be slightly different from the pictures shown on website caused by many factors such as brightness of your monitor and light brightness. 3. Please allow slight manual measurement deviation for the data.
