BAOFENG UV-B6 UHF / VHF Walkie Talkie

The UV-B6 is a full featured two way radio and hand held transceiver with long range capabilities up to 15km. Each radio comes with a charger, antenna, and everything you need to get started communicating conveniently at a long range, whether in a recreational context like camping or on site at your business. The UV-B6 includes many perks that elevate it above an average Walkie Talkie, such as VOX (Voice Operated Exchange) which makes it unnecessary to push a button to talk. Its other features include a built-in high illumination flashlight and an emergency alarm.
Features
99 Memory ChannelsSelect desired channel from 1 to 98. No.99 is Scanning channel.
50CTCSS / 104DCSAllows you to ignore unwanted calls from other persons who are using the same frequency.
2000mAh Battery PackOffers long using time up to 10 hours.
Effective Range up to 15KMSo you and your driving, hunting or hiking partner can keep in touch.
VOX voice-activated controlFor hands-free operation. Five sensitivity levels let you adjust the volume at which the radio picks up your voice.
Built-in LED FlashlightIlluminates the path ahead.
Additional FunctionsTime-Out Timer (TOT), Scan, Voice Prompt, Emergency Alarm, Battery Low Alert, Monitor, Busy Channel Lock-Out (BCL).
Specifications
Brand
Baofeng
Model Number
UV - B6
Frequency Bands
UHF, VHF
Channels
99 Channel
Frequency Stability
+/- 2.5 PPM
Feature
Long-lasting Battery Life
Main Functions
Busy Channel Lockout (BCL), Time-Out Timer (TOT), VOX, CTCSS/DCS, PC Programmable
Special Function
FM Radio, Reporting Number Command, DTMF, Battery Save, Low Power Alarm, Dual Band, Dual Display, Dual Frequency, Scan, PTT-ID, Reverse Frequency, W / N, ANI-ID, 1750HZ Relay Forwarding Confirmed
Power Supply
1 x 7.4V / 2000mAh Lithium Battery
Voltage
DC 7.4V (Li-ion Battery)
Antenna Impedance
50ohm
Transmitter
Output Power (high/low)
5W / 2W
Maximum Frequency Deviation (broadband/narrowband)
Less than 5KHz (W), Less than 2.5KHz (N)
Adjacent Channel Power
65dB (W), 55dB (N)
CTCSS/CTTCS Frequency Deviation (broadband/narrowband)
0.7 +/- 0.1KHz (W), 0.4 +/- 0.1KHz (N)
Modulation Type
FM (F3E)
Modulation Sensitivity
8 - 12mV
Receiver
Receiveing Sensitivity (broadband/narrowband)
Less than 0.20 micro voltage (12dB SINAD)
Audio Power
1W
Audio Distortion
5 percent
Intermodulation (broadband/narrowband)
More than 65dB (W), More than 55dB (N)
Adjacent Channel Selectivity (wide/narrow)
More than 65dB (W), More than 55dB (N)
Product Weight
120g
Product Size
11.5 x 5.8 x 3.6 cm
Package Weight
600g
Package Size
18.5 x 12.5 x 11.0 cm
Package Includes
1 x Walkie Talkie, 1 x Antenna, 1 x Lithium Battery Pack, 1 x Lithium Battery Charger, 1 x Power Adapter, 1 x Belt Clip, 1 x Lanyard, 1 x English User Manual
