Anet V1.0 3D Printer Controller Motherboard Ramps 1.4 Update Version

This Anet V1.0 3D Printer Controller Motherboard features optimized layout and thermal design alignment for more stable performance and large USB for convenient and stable wiring.
Stable Performance
Thanks to the optimized layout and thermal design alignment, its performance is more stable.
Highly Integrated One-Board Design
Solves the complicated Ramps 1.4 combination, easy to failure and other problems.
Auto-Leveling Proximity Probe Supported
So you can add your own debugging auto-leveling.
Large USB Design
For stable connection and simple interface as well as convenient and more steady wiring.
PWM DC 3 Channel Output
1 channel for high-current, 3 channel for mid-current , 2-channel for low current.
Better Heat Dissipation
Adopting high-performance low on-resistance Mos tube driver for better cooling performance.
Adopting ST Original Power Chip
Fit for 12-24V power input, to solve the heat problem of Ramps voltage converter chip.
Reduce The Hot Bed Current to 1/4
Accept 24V input, with the same system power, can decrease the hot bed current to 1/4, to solve the problem of hot bed MOS tube heating effectively.
Replace Ramps 1.4
By using the open-source firmware Marlin (the same configuration of Ramps 1.4), replace it instead of Ramps 1.4.
Others
Can be directly connected Ramps 1.4, 2004LCD control board and 12864LCD control board (remove the L-shaped adapter board).
Specifications
Model V1.0
Product Weight61g
Package Weight80g
Product Size10 x 9.5 x 2 cm
Package Size16 x 11 x 3 cm
Package Contents1 x Anet V1.0 3D Printer Controller Motherboard
